Countersink DIN 335 C 90 deg nominal diameter 12.4 mm HSS over-long Z.3 TECWERK
Machining

Countersink DIN 335 C 90 deg HSS over-long Z.3 TECWERK

Description
Article number: 2000865392
EAN: 4015448586845

HSS · DIN 335 C · With extended shank · 3 cutters · Countersink angle 90° · Straight shank · For countersinking and deburring holes in steel, cast iron, and non-ferrous metals · The 3 cutting edges afford a chatter-free cut Further technical information: · Overall length: Extra-long · Feed in steel up to 500 N: 0,14mm/rev
Specifications
Coating: Uncoated
Nominal Ø: 12.4 mm
Small Ø: 2.8 mm
Shank Ø: 8 mm
Overall length: 108 mm
Countersink angle: 90 °
Standard: DIN 335 C
No. of cutters: 3
Cutting material: HSS
Type: Extra-long
Marker: TECWERK
Downloads
Schnittwerttabelle
